Digital devices often operate using different voltage levels. A sensor may run at 3.3V while a microcontroller outputs 5V, which creates a risk of damaging hardware if signals are connected directly. A logic level converter is used to safely convert one logic voltage to another so different components can communicate without harm.
This Logic Level Converter Tool lets you enter the source and target voltage and calculates recommended resistor values when using a voltage divider. It also helps determine whether you need a unidirectional divider or a bidirectional converter depending on the signal. This is useful when working with Arduino, ESP32, Raspberry Pi and other microcontroller projects.
Logic Level Converter Tool
Level shifting is one of the most important fundamentals when mixing 3.3V and 5V hardware. Using incorrect voltages can fry IO pins, produce unstable readings or cause communication failure. A voltage divider works well for slow or one way signals like UART, GPIO triggers or simple control lines. For high speed protocols such as I2C or SPI, a dedicated level shifting IC is recommended for clean and reliable communication.
Common use cases for this tool include:
โข Converting 5V Arduino output to 3.3V sensor input
โข Protecting low voltage microcontrollers like ESP8266 or ESP32
โข Designing resistor based level shifters for GPIO control lines
โข Learning safe voltage handling for electronics prototyping
